2.5 Ton Cpcd25 Forklift with Diesel Engine Ce Approved

Our company adheres to the development direction of 'industrialization' and strives to become a well-known forklift engine repair, 2 tonne electric pallet truck, Fork Sleeve supplier at home and abroad. We are always waiting for your visit and guidance! We are willing to work together with you to create a better tomorrow and work hard to realize the Chinese dream. Our professional and excellent after-sales service team provides you with free one-to-one consultation service.

Product Title: Engine Timing Gear Housing

Product Model:4D35G-16001/16003 for Xinchai Engine



















Item	Description
Product Name	Engine Timing Gear Housing
P/N	4D35G-16001 16003
Applied Model	Forklift Diesel Engine Xinchai 4D35G
Net Weight (kg)	18.20
Gross Weight (kg)	21.60
Qty per Carton	1
Carton Size (cm)	62*40*12







Forklift Diesel Engine Timing Gear Housing Function:

Forklift diesel engine timing gear housing is installed in the front section of body and is integral or separate from the body. It is used to install fuel injection pump, governor, timing gear and some components. The timing gear housing cover is used to seal the timing gear chamber and prevent oil leakage.



Root Causes Analysis of Abnormal Noise of Timing Gear Chamber of Forklift Diesel Engine



1. Poor lubrication caused by blocked nozzle holes in main oil passage;

2. Improper assembly or too thin spacer with too little clearance. The cam timing gear assembly is skewed during maintenance, the unevenness causes friction between the boss and the flange, and sharp metal noise occurs;

3. The gear meshing gap is too large. When there is an impact load, the tooth surfaces collide with each other and produce abnormal noise;

4. Timing gear machining accuracy is low, there are burrs, poor contact of gear pair;

5. The flange fixing bolts are loose, the gear moves axially, the center of the shaft and hole is offset, the gear meshes unevenly and sways.



We always adhere to the "quality, reputation" as the purpose of service, and our 2.5 Ton Cpcd25 Forklift with Diesel Engine Ce Approved have been gradually developed overseas markets. We adhere to the principle of fairness, justice and reasonable competition. Our company wants to interpret dedicated, pragmatic and persevering corporate spirit to customers from all over the world.
